The 1783-BMS12T4E2CGP is a Stratix 5700 managed industrial Ethernet switch with 18 ports, including 12 Fast Ethernet RJ45 ports, 4 PoE ports and 2 Gigabit combo ports.
Marque :
PLCNuméro d'article :
1783-BMS12T4E2CGPLester :
Verify from official installation drawingDimension :
Verify from official installation drawingPays d'origine :
12–48 V DC switch input; 44–57 V DC PoE inputCode SH :
Stratix 5700 18-Port Managed SwitchLa description :
The 1783-BMS12T4E2CGP is a Stratix 5700 managed industrial Ethernet switch with 18 ports, including 12 Fast Ethernet RJ45 ports, 4 PoE ports and 2 Gigabit combo ports.Click “+” to expand more specifications.
Source: Official publication 1783-TD002 and the exact official product cutsheet support 1783-BMS12T4E2CGP technical specifications. Verify the full catalog number, 85–132 V AC class, 12 total output, duty ratings, frame, enclosure, input, filtering, braking and Exact unit type configuration before replacement.
1783-BMS12T4E2CGP is a Stratix 5700 18-Port Managed Switch documented in official publication 1783-TD002.
1783-BMS12T4E2CGP provides 18 total Ethernet ports; verify each field circuit against the official wiring diagrams.
1783-BMS12T4E2CGP uses 12 Fast Ethernet RJ45 ports according to official publication 1783-TD002.
1783-BMS12T4E2CGP uses 4 PoE ports plus 2 Gigabit combo ports; confirm the connected load voltage and output type before wiring.
1783-BMS12T4E2CGP uses 12–48 V DC switch input; 44–57 V DC PoE input incoming power; verify the line terminals and fuse arrangement.
1783-BMS12T4E2CGP is specified with Full firmware with CIP Sync and DLR and DIN-rail managed industrial switch.
1783-BMS12T4E2CGP requires verification of the complete catalog number, incoming power, I/O voltage, output type, terminal wiring and connected Bulletin 1783 system.
Official manufacturer-reference information for the 1783-BMS12T4E2CGP Stratix 5700 18-Port Managed Switch.
Official publication 1783-TD002 identifies 1783-BMS12T4E2CGP and its documented electrical and I/O data.
OFFICIAL MANUALSend the complete model, quantity, nameplate photos and your technical or purchasing question.
Technical statements on this page are limited to official manufacturer publication 1783-TD002 for 1783-BMS12T4E2CGP. No third-party product sources were used.
1783 identifies the bulletin 1783 industrial network family; BMS12T4E2 identifies the 12 fe rj45, 4 poe and 2 ge combo port arrangement; CGP identifies the full-firmware poe managed-switch configuration.
Bulletin 1783 controller family.
12 FE RJ45, 4 PoE and 2 GE combo port arrangement.
Full-firmware PoE managed-switch configuration.
BMS identifies the Stratix 5700 managed-switch family; the remaining code specifies the 18-port PoE hardware and full firmware.
Managed switching between controllers, operator interfaces, drives and industrial Ethernet devices.
Network and power delivery for compatible industrial cameras, access points and other PoE devices.
Device Level Ring applications requiring fast network fault detection and recovery.
CIP Sync distribution for coordinated industrial Ethernet devices.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
