Bently Nevada 330185-01 3300 XL Precision Micrometer
Bently Nevada 330185-01 3300 XL Precision Micrometer
Bently Nevada 330185-01 3300 XL Precision Micrometer

Bently Nevada 330185-01 3300 XL Precision Micrometer

3300 XL · PRECISION MICROMETER

330185-01

330185-01 — A precision micrometer for controlled target positioning during 3300 XL proximity transducer system verification.

PRODUCTPrecision micrometer
SCALE RANGE0–1 in
TARGET4140 steel · 30.5 mm
USETransducer verification
MANUFACTURERBently Nevada · Baker Hughes
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Renseignez-vous maintenant
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
BENTLY NEVADA ● 3300 XL VERIFICATION KIT
PRECISION MICROMETER

330185-01

English units · 0–1 in scale · 30.5 mm target

3300 XL Precision Micrometer

VERIFICATION ROLE
330185-01 — A controlled mechanical target-positioning tool for verifying compatible 3300 XL proximity transducer systems.
SCALE OPTION
The 01 option identifies the micrometer with English units and a 0–1 inch measurement range.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
CONFIGURATION DECODING

Model code at a glance

330185
Base model3300 XL Precision Micrometer
01
Scale unitsEnglish units · 0–1 in
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

3300 XL Verification Kits Official PDF ↗
3300 XL PRECISION MICROMETER

Engineering data at a glance

Click “+” to expand more specifications.

HEIGHT226 mm (8.9 in)
WIDTH274 mm (10.8 in)
LENGTH356 mm (14.0 in)
WEIGHT6.8 kg (14.5 lb)
Dimensions and performance from manufacturer verification-kit data.
Verification setup Confirm the complete transducer system, adapter thread and test conditions before verification.
General Information −
BrandBently Nevada
Part number330185-01
Product type3300 XL Precision Micrometer
Product family3300 XL Monitor and Transducer Verification Kits
Measurement principlePrecision mechanical target positioning
OutputActual target position for comparison with Proximitor Sensor voltage
Verification Performance ＋
ISFActual±5 mV/mil relative to the actual transducer system
DSLActual±0.5 mil relative to the actual transducer system
Measurement basis3300 XL 8 mm 5 m system at 22 ±3°C (72 ±5°F)
Mechanical and Adapter Details ＋
TargetAISI 4140 alloy steel · 30.5 mm (1.20 in) flat target
Micrometer scaleEnglish units · 0–1 in
Adapter thread sizes1/4, 3/8, 1/2, 5/8 in · M8, M10, M14, M16
Case constructionFiberglass and plastic
Verification useAcceptance testing and probe-curve generation for compatible systems
Case Size and Handling ＋
Case size: 226 × 274 × 356 mm (8.9 × 10.8 × 14.0 in). Total system weight: 6.8 kg (14.5 lb).
Source: Bently Nevada 141196 Rev. G. Verification values are relative to the actual compatible transducer system under the manufacturer stated conditions.
FAQ

Questions Buyers Ask Most

What is 330185-01 used for?＋

330185-01 is a precision micrometer used to move a target toward or away from a probe tip in controlled increments for compatible 3300 XL transducer verification.

What scale option does 330185-01 use?＋

For 330185-01, option 01 specifies English units with a 0–1 inch micrometer scale.

How does 330185-01 support verification?＋

The 330185-01 moves the supplied target in measured increments while the Proximitor Sensor output is recorded, allowing comparison with the transducer system performance specification.

What are the target and adapter details for 330185-01?＋

The 330185-01 uses a 30.5 mm flat AISI 4140 steel target and includes adapters for 1/4, 3/8, 1/2, 5/8 inch, M8, M10, M14 and M16 threads.

What should I provide for a 330185-01 quotation?＋

Send the complete 330185-01 part number, quantity, transducer system, adapter thread requirement and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete part number, transducer system and adapter requirement for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Manuals and Official References for
330185-01

Official manufacturer documentation for the Bently Nevada 3300 XL Precision Micrometer 330185-01.

Official manufacturer datasheet

Bently Nevada datasheet 141196 Rev. G identifies 330185-AXX as the 3300 XL Precision Micrometer and option 01 as English units with a 0–1 inch range.

OPEN OFFICIAL DATASHEET PDF

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements and ordering-code meanings use Bently Nevada / Baker Hughes datasheet 141196 Rev. G.

TRANSDUCER VERIFICATION WORKFLOW

How 330185-01 Supports 3300 XL Transducer Verification

Bently Nevada is the manufacturer. 330185-01 is the precision micrometer used to position the supplied target during compatible proximity transducer system verification.

Bently Nevada · BRAND
3300 XL Verification KitPRODUCT FAMILY · VERIFICATION WORKFLOW
TARGET POSITIONING

Precision Micrometer

Move the AISI 4140 steel target toward or away from the probe tip in controlled micrometer increments.

VOLTAGE RECORDING

Digital Voltmeter

Record the Proximitor Sensor output voltage at each target position to generate or verify the probe curve.

RESULT CHECK

Performance Comparison

Compare the recorded curve and derived values with the compatible transducer system specification.

System relationship: the actual probe, extension cable and Proximitor Sensor combination must match the intended 3300 XL system and test conditions.
APPLICATION AREAS

Verification uses for 330185-01

Transducer Acceptance TestingSupports acceptance testing of compatible transducer systems against published performance specifications and API 670 requirements.
Probe Curve GenerationProvides controlled target movement for recording Proximitor Sensor output and generating a probe curve.
APPLICATION CENTER 330185-01 3300 XL Precision Micrometer
Proximitor Sensor VerificationSupports verification of compatible proximity probe, extension cable and Proximitor Sensor combinations.
Shaft Position Monitor ChecksCan be used to verify compatible shaft-position monitor behavior with controlled target movement.
