ABB SPDSM04 DSM04 pulse input module processes eight isolated pulse channels for Symphony Plus DCS frequency, counting, and duration applications.
Marque :
ABBNuméro d'article :
DVP24ES00R2Lester :
0.3 kgDimension :
3.56cm x 17.78cm x 29.85cmPays d'origine :
SWEDENCode SH :
8537101190La description :
Eight-channel pulse input module for ABB Symphony Plus HR DCS systems
The ABB SPDSM04, also known as DSM04, is a Symphony Plus HR Series pulse input module used for high-speed pulse signal acquisition in DCS automation systems. It processes up to eight optically isolated pulse input channels and supports 5 VDC, 24 VDC, and 50 mVpp to 10 Vpp signal ranges. The module is suitable for frequency measurement, pulse counting, duration monitoring, and rotating equipment feedback in process control systems.
|
RFQ：please contact sales manager Nina |
||
|
Whatsapp：+86 18030235312 |
Email：sales8@askplc.com |
Address:Xiamen,Fujian,China |
Technical Parameters
Brand
ABB
Number of Input Channels
8 channels
Model
SPDSM04 / DSM04
Channel Type
Pulse Input / Digital Input
Product Type
I/O Module
Input Signal Range
5 VDC, 24 VDC, 50 mVpp to 10 Vpp
Category
DCS
Max. Input Frequency
50 kHz at 50% duty cycle
Series
ABB Ability Symphony Plus / HR Series
Operating Temperature
0 to 70 °C
|
FAQ |
|
Q1: What is ABB SPDSM04 used for? |
|
It is used to acquire pulse signals from field devices for counting, frequency, period, or duration measurement. |
|
Q2: Is SPDSM04 the same as DSM04? |
|
SPDSM04 is the Symphony Plus ordering/model format, while DSM04 is commonly used as the shorter module name. |
|
Q3: What signal types can SPDSM04 accept? |
|
It supports 5 VDC contact input, 24 VDC contact input, and low-level pulse signals from 50 mVpp to 10 Vpp. |
|
Q4: What should be checked before replacement? |
|
Check the part number, termination unit, signal voltage range, function code configuration, channel wiring, and controller compatibility. |
|
