The ABB CI522-MODTCP is an AC500/S500 Modbus TCP server interface with two 10/100BASE-TX ports, 8 DI, 8 DO and 8 software-configurable digital I/O channels. It supports fast-counter functions and compatible S500 expansion.
Modbus TCP server interface · 2-port 10/100BASE-TX switch · 8 DI · 8 DO · 8 configurable digital I/O.
CI522-MODTCP publishes its integrated digital channels and compatible S500 expansion to a Modbus TCP client through two switched RJ45 ports.
Confirm order number 1SAP222200R0001, standard or XC version, IP settings, Modbus mapping, configurable-channel direction, 24 V DC wiring and S500 station layout before replacement.
Source: ABB CI522-MODTCP data sheet 3ADR010004, ABB product page for 1SAP222200R0001, and ABB Automation Builder compatibility information. Values apply under ABB’s stated operating conditions.
Official ABB product and technical data for CI522-MODTCP, complete order number 1SAP222200R0001.
ABB documents CI522-MODTCP as a Modbus TCP server communication interface with 8 digital inputs, 8 digital outputs and 8 configurable digital I/O channels. It uses two 10/100BASE-TX RJ45 ports, supports fast counters and is available in standard and XC order variants.
OFFICIAL DATASHEET ↗Send the complete model, quantity, network configuration and your technical or purchasing question.
✉ EMAILSource: ABB 3ADR010004 and ABB official product page for 1SAP222200R0001; lifecycle phase is listed as Active.
ABB ↗ is the brand, AC500/S500 is the automation platform, CI522-MODTCP is the complete module model, Modbus TCP digital I/O communication interface is the product type, and 1SAP222200R0001 is the standard order configuration.
Modbus TCP server for digital remote I/O.
Two switched 10/100BASE-TX RJ45 ports.
8 DI, 8 DO and 8 configurable digital channels.
Up to 10 compatible S500 I/O modules.
Publishes fixed and configurable digital channels to a compatible client.
Eight DC channels are assigned as inputs or outputs in the user program.
Counter status and control occupy defined input and output process bytes.
Extends the station with compatible S500 modules under ABB’s architecture rules.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
